ZWS型振網篩產品概述

    ZWS型振網篩適用于對松散的復合肥料及其它松散的細物料進行分級。 ZWS型振網篩是吸取美國先進技術自行設計制造的，以振動電機做為振動源，牽引篩網及篩框振動，實現物料分級。ZWS振網篩由給料器、篩箱篩面機體料斗和振網裝置組成。材料由給料器均勻給到篩面，分成篩上產品與篩下產品（單層篩）。本系列振網篩以振動電機為振動源，牽引篩網上下振動，篩機振幅可調，以適應不同物料的分級。篩網的振動，一方面可防止篩網堵塞，同時使物料拋起向前彈跳實現分級，因而振網篩的篩分效率高。

Product overview
   ZWS type vibrating screen is suitable for loose sorted compound fertilizer and other loose fine.ZWS type vibrating screen is to learn the advanced technology to design and manufacture, with vibration motor as vibration source, traction screen and screen frame vibration, realize the material classification.ZWS vibration screen consists of feeder, screen box body hopper and network devices.Material by feeder evenly to screen surface, divided into oversize product and undersize (single screen).This series of vibration screen with vibrating motor as vibration source, traction vibrates sieve, sieve machine adjustable amplitude, to adapt to the different material classification.The vibration of the screen, on the one hand, can prevent the mesh plug, at the same time make material into jumping forward classification, and vibration mesh high screening efficiency.

ZWS型振網篩主要特點

1.密封防塵，維修方便。
2.篩機振幅可調，篩分效率高。
3.生產能力大，動負荷小，噪音低。


Features
1. Seal dustproof, easy to maintenance.
2. Screen machine adjustable amplitudes, high screening efficiency.
3. The production capacity of large, dynamic load is small, low noise.

ZWS型振網篩工作原理:
電磁振動高頻振網篩采用全新原理，篩面振，篩箱基本不參振動，激振力驅動振動系統激振篩面，震動系統設計在近共振狀態工作，可用較小的驅動力達到所需的工作參數，而節省能源。此外，篩面高頻震動，振幅1-4mm，可達8-10倍重力加速度，是一般篩分設備震動強度的2-4倍，所以不堵篩孔，篩面自清洗能力強，篩分效率高，處理能力大，非常適用于細顆粒物料的篩分,4平米處理能力在200噸左右.篩分效率在60%以內，如果濃度調整好，可以達到80%上。 用于鐵選廠提高篩分、提高產量的理想設備----電磁振動高頻振網篩。|
Working principles
Electromagnetic vibration of high frequency vibration screen with new principle of vibration screen surface, basic no vibration sieve box, vibration force drive vibration  surface vibration system, vibration system design in the near resonance state, smaller driving force to achieve the required parameters are available, and save energy.In addition, the high frequency vibration screen surface, amplitude 1-4 mm, up to 8 to 10 times the gravitational acceleration is generally 2 to 4 times of screening equipment vibration, so don't block the mesh, screen surface self-cleaning capability is strong, high screening efficiency, processing capacity is big, very suitable for fine particle material screening, 4 square meters capacity around 200 tons. Screening efficiency within 60%, adjust, if the concentration can reach 80%.For iron mill plant to improve screening and ideal equipment to improve the yield of high frequency vibration, electromagnetic vibration screen.|

ZWS型振網篩產品型號及技術參數

Parameters

2 ZWS-12-30
┬ ┬ ┬ ┬
│ │ │ │
│ │ │ │
│ │ │ │
│ │ │ └──────────　篩面長度dm
│ │ │
│ │ └───────────-　篩面寬度dm
│ │
│ └─────────────　軸偏心振動器
│　
└──────────────-　軸偏心振動器



型號	篩 面					給料粒度（mm）	處理量（t/h）	振次（l/min）	雙振幅（mm）	功率（kw）	外形尺寸 長×寬×高（mm）	總重量（kg）
	層數	面積（m2）	傾角（°）	篩孔尺寸（mm）	結構
ZWS1230	1	3.6	37	10×40	編織	≤60	30-35	1450	3-5	0.85×2	3090×1700×3169	1623
2ZWS1230	2	3.6	33	上：4×50 下：1.4×50	編織	≤60	30-35	1450	3-5	0.85×2	3301×1680×3300	2300
ZWS1245	1	5.4	37	上：4×50 下：1.4×50	編織	≤60	45-60	1450	3-5	0.85×3	4350×1660×5066	2631
2ZWS1245	2	5.4	37	上：4×50 下：1.4×50	編織	≤60	45-60	1450	3-5	0.85×3	4496×1660×5648	3612
ZWS1260	1	7.2	20	4×25	編織	≤60	60-90	1450	3-5	0.85×4	6576×1660×4240	3290
2ZWS1260	2	7.2	37	上：4×50 下：1.4×50	編織	≤60	60-90	1450	3-5	0.85×4	5678×1660×6156	4532
