煤詳細介紹：
    ZSM座式脫水振動篩運動軌跡為直線，是根據JB2444--86《ZSM型煤用座式雙軸振動篩》標準生產的，全系列共有十六種規格，可供選煤、選礦、電力、制糖、制鹽等工業部門，對中細粒級物料進行干濕式分級、脫水、脫介、和脫泥。篩機處理能力大，篩分效率高。
   ZSM type dewatering vibrating screen trajectory is straight line, according to JB2444-86 "The ZSM Type Coal with a Type Biaxial Vibrating Screen" standard production, the whole series of sixteen kinds of specifications, available for coal preparation, ore dressing, power, sugar, salt and other industrial departments, to dry wet type of fine grained material classification, dewatering, medium, and desliming.Sieve machine processing capacity is big, high screening efficiency.

    DSM吊式脫水振動篩運動軌跡為直線，是根據QJ/AK02.06--89《DSM型煤用吊式雙軸振動篩》標準生產的，全系列共有四種規格，可供選煤、選礦、電力、制糖、制鹽等工業部門，對中細粒級物料進行干濕式分級、脫水、脫介、和脫泥。篩機處理能力大，篩分效率高。
    DSM hanging dewatering vibrating screen trajectory is straight line, according to QJ/AK02.06-89 "Hanging Biaxial Vibrating Screen Used DSM Type Coal" standard production, the whole series of a total of four kinds of specifications, available for coal preparation, ore dressing, power, sugar, salt and other industrial departments, to dry wet type of fine grained material classification, dewatering, medium, and desliming.Sieve machine processing capacity is big, high screening efficiency.

脫水篩(脫水振動篩)產品概述：
   脫水篩(脫水振動篩)是煤泥脫水作業的專用設備，廣泛適用于煤泥回收，壓濾隔粗、過濾隔粗，其他極細物料的脫水、回收等工藝條件。脫水篩(脫水振動篩)采用了雙電機自同步技術，通用型偏心塊、可調振幅振動器。主要由篩箱、激振器、支承系統及電機組成。通過膠帶聯軸分別驅動兩個互不聯系的振動器作同步反向運轉，兩組偏心質量產生的離心力沿振動方向的分力疊加，反向離心抵消，從而形成單一的沿振動方向的激振動，使篩箱做往復直線運動。

Product overview
   Dewatering screen (dehydration vibrating screen) is the special equipment  for coal slime dewatering operation, widely used in coal slime recovery, filter isolate thick thick, filtering, dehydration and other very fine material recycling process conditions, etc.Dewatering screen (sieve dehydration) adopted double motor synchronization technology, universal eccentric block, adjustable amplitude of vibrator.It is mainly composed of screen box, vibrator, supporting system and motor.Coupling respectively by tape drive two mutually contact vibrator are synchronous reverse operation, two groups of eccentric mass produced by centrifugal force along the direction of vibration force component overlay, reverse centrifugal offset, so as to form a single, along the direction of vibration induced vibration makes the screen box do reciprocating linear motion.

脫水篩(脫水振動篩)產品特點： 　　
1、篩機整體為水平安裝，但篩網呈負角安裝，以保證強制脫水效果； 　　
2、篩網可選擇不銹鋼復合篩網，張緊式安裝，或不銹鋼焊接條縫篩板，壓緊式安裝，以滿足不同需要；可通過變頻器隨時調整振動頻率以達到最佳脫水效果； 　 　　
3、采用自同步液體潤滑振動器激振，篩框采用特殊降噪材料，并用高強螺栓聯接，確保篩機工作可靠和工作噪聲降低，整機工作噪聲85dB(A),較同類篩機降幅約為15dB； 　　
4、入料段設置弧形篩面，提高脫水效率；　　
5、設置給料箱，保證物料均勻給入篩面； 　　
6、配有整體底架便于搬運和安裝；　
7、依靠篩上濾層截留細粒和積壓脫水。 　

Features　
1, screen machine installation is level, but negative angle to install mesh, to ensure that the mandatory dehydration effect;
2, screen mesh is available in stainless steel composite, tension type installation, or stainless steel welding seam sieve plate, pressure type installation, to meet different needs;Can be adjusted at any time by the frequency of vibration frequency in order to achieve the best effect of dehydration;
3, using the synchronous fluid lubrication vibrator excitation, sieve box adopts special noise reduction materials, with high-strength bolt connection, ensure the machine working reliability and noise reduction, working noise of 85 db (A), compared with the similar machine A drop of about 15 db.
4, into the period of setting arc screen surface, improve the efficiency of dehydration;
5, set the feeding box, ensure material evenly into the screen surface;
6, with a whole chassis to facilitate handling and installation;
7, rely on screen filter layer intercept backlog of fine particle and dehydration.

座式脫水振動篩選用須知：
　 1、篩機分單層和雙層，并有單電機齒輪拖運和雙電機自同步拖運之分。單電機拖運有左裝和右裝之分。
　 2、篩網結構有條縫篩網，沖孔篩板，如選用編織篩網和橡膠篩板可按要求設計。當選用及訂貨時,應對篩子的布置方式,篩縫尺寸作出決定,未作確定時,按右式布置灑縫0.5毫米供貨(電機位于料流方向的左側或右側).
　 3、篩面傾角可在-2～10°內調整.選用其它角度,用戶可自調整.
　 4、基礎螺栓除ZSM185振動篩螺栓有M20和M16兩種規格外，其余所有篩機基礎螺栓均為M20，皆由用戶自備。

Selection guidelines(ZSM)
1, single and double screen points, and a single motor gear hauling and double self synchronous hauling.Of single motor haulage have left and right installation.
2 screen mesh structure have a line of sew, punching screen plate, if choose woven mesh and rubber sieve plate can be designed as required.Elected to use and when you place an order to sieve arrangement, sieve seam size to make a decision, not sure when the right type is decorated is aspersed seam supply 0.5 mm (motor is located in the left or right) material flow direction.
3, the screen surface angle can be adjusted within 2 ~ 10 °. Choose other point of view, the user can be adjusted since.
4 bolt, foundation bolt except ZSM185 vibrating screen a M20 and M16 two specifications, the rest all foundation bolts are M20, sieve machine is own by the user.

吊式脫水振動篩選用須知：
1、篩機分單層和雙層，均為單電機齒輪拖運。
2、篩網結構有條縫篩網，沖孔篩板，如選用編織篩網和橡膠篩板可按要求設計。
3、基礎螺栓:吊掛裝置基礎螺栓為M24，電動機基礎螺栓為M16，皆有用戶自備。
Selection guidelines(DSM)
1, single and double screen points, both for single haulage motor gear.
2 screen mesh structure have to sew, punching sieve plate, if choose woven mesh and rubber sieve plate can be designed as required.
3, foundation bolt, foundation bolt hanging device for m2-m24, motor foundation bolt as the M16, both users should bring along their own.

脫水篩(脫水振動篩)產品選型及定貨：注明篩網結構（編制、沖孔、條縫）、網孔尺寸、處理量、物料入粒粒度。

Dewatering screen(dehydration vibrating screen) product selection and order: indicate the mesh structure (preparation, punching and slit), mesh size, capacity, material into the abrasive.
